Storage systems

Standard cabinets

Waldner Education's traditional open or closed storage cabinets with a total height of 2090mm are an excellent option for teachers or assistants who have a lot of storage space in their classroom or prep room. They offer enough space for everything that is needed on a regular basis or what needs to be stored (conform EN DIN 16121 in DIN EN 16122). Take advantage of the various options, such as a glass or closed door, to adapt this model perfectly to your needs.

• Width: 450 to 1200 mm
• Depth: 350 or 550 mm
• Revolving doors, folding doors or drawers
• Optional: exhaust air connection, pull-out shelves (at 550 mm cabinet depth) and fully extendable drawers (at 550 mm cabinet depth)
• Not approved for the storage of acids, alkalis, flammable liquids, gas cylinders, self-igniting or self-decomposing substances

GARAGE CABINET FOR LEARNING BOXES AND LEARNING CABINETS 3X1

Garage cabinet the space-saving, demountable solution for perfect order in the room, equipped with 2 hinged doors with sliding base made of sheet steel, suitable for max. 3x1 mobile learning lockers and a top section that offers space for 27 learning boxes because there are 2 middle walls.

Features:

• Park the 3x1 learning cabinet at ground level by using the sliding base
• Durable use thanks to robust body construction and high-quality equipment
• Flexible interior design with 3x2 shelves or 3 pairs of pull-out panels for teaching boxes

GARAGE CABINET FOR TABLEAUX AND MULTI-MOBILE

Garage cabinet for perfect order in the room, max. 2 hinged doors with sheet steel sliding bottom, suitable for max. 2 pcs. of Multi-Mobile and experiment panels, the upper part with 1 middle wall, space-saving and demountable.

Features:

• Park the Multi-Mobile at ground level using a tow bar
• Durable use thanks to robust body construction and high-quality equipment
• Flexible interior design with 2x2 shelves or 2 pairs of pull-out panels for experimentation

PHARMACY CABINET

A pharmacy cabinet is a narrow, elongated cabinet that can be pulled all the way out. This gives you access to various racks that you can provide with items in an orderly manner. This way, you won't have to search for a long time when you need something from this cabinet. The pull-out pharmacy cabinets from Waldner Education are extremely space-saving. Liquid and solid substances can be stored in pull-out wire baskets with drip trays in accordance with DIN EN 16121 and DIN EN 16122..

Features:

• Width: 600 or 900 mm
• Height: 2090 mm
• Depth: 550 mm
• Drawers: height-adjustable, each with five drawers, accessible from both sides
• Four height-adjustable legs
• Optionally available with exhaust air connection
• Not approved for the storage of acids, alkalis, flammable liquids, gas cylinders, self-igniting or self-decomposing substances

The FWF 90 fire-resistant hazardous material cabinet is perfect for the safe and professional storage of flammable liquids, 3 height-adjustable shelves and 1 collection tray with perforated metal insert

Features:

• In the event of a fire, automatic closing thanks to a current-independent thermal release
• 90 minutes of fire resistance thanks to sheet steel body construction
• Complies with DIN EN 14470-1, DIN EN 14727, EK5/AK4 09-10:2009, TRGS 510 Annex 3 and TRbF20 Annex L
• Certified according to the GS test principles
• Safety thanks to the possibility of connection to a permanent ventilation system via an exhaust air connection

Up to 4 compressed gas cylinders of 50 litres each can be safely and correctly stored in this fire-resistant cabinet.

Features:

• Depending on the version, between 30 (G30) and 90 minutes (G90) fire resistance thanks to the sheet steel body construction
• Corresponds to DIN EN 14470-2, DIN EN 14727, EK5/AK4 09-10:2009 and TRGS 510 chapter. 10
• Certified according to the GS test principles
• Safety thanks to the possibility of connection to a permanent ventilation system with uniform ventilation of the interior via exhaust air connections
• Easy installation thanks to pipe and cable penetrations in the cabinet roof
• Possible inclusion of pressurized gas reducing stations and gas fittings using the integrated mounting rail
• Easy handling thanks to the roll-up ramp for compressed gas cylinders

This special cabinet is suitable for storing acids and alkalis and therefore complies with DIN EN 16121 and DIN EN 16122 standards. The laboratory cabinet has separate compartments for acids and alkalis and a connection to a permanent ventilation system. The adjustable feet ensure good stability, and the four adjustable shelves allow for customization according to your needs.

Features:

• For storing limited quantities of acids and alkalis.
• Not suitable for storing flammable liquids, pressurized gas cylinders, or self-igniting or self-decomposing substances.
• Connection to a permanent ventilation system.
• 4 fixed or pull-out shelves, 4 adjustable feet.
• Separate compartments for acids and alkalis.
• Polypropylene drip trays.
• Coated fittings.
• Hinged door(s), SCALA bow handle, stainless steel.
